STMicroelectronics SPC572L series Reference Manual page 1843

RM0400
Field
State Hit 3. This bit is set when State3 is hit/encountered in any of the active sequences
3
0 State not hit
SH3
1 State hit
State Hit 4. This bit is set when State4 is hit/encountered in any of the active sequences
4
0 State not hit
SH4
1 State hit
State Hit 5. This bit is set when State5 is hit/encountered in any of the active sequences
5
0 State not hit
SH5
1 State hit
State Hit 6. This bit is set when State6 is hit/encountered in any of the active sequences
6
0 State not hit
SH6
1 State hit
State Hit 7. This bit is set when State7 is hit/encountered in any of the active sequences
7
0 State not hit
SH7
1 State hit
Sequence 1 Active State. Two consecutive read cycles are required to know the active state. These bits
capture the active state of sequence 1 at the clock when these bits are read. The active state might be
different in the previous clock and the next clock.
000 State0 is the active state
001 State1 is the active state
10 –8
010 State2 is the active state
SAS1
011 State3 is the active state
100 State4 is the active state
101 State5 is the active state
110 State6 is the active state
111 State7 is the active state
Sequence 2 Active State. Two consecutive read cycles are required to know the active state.These bits
capture the active state of sequence 2 at the clock when these bits are read. The active state might be
different in the previous clock and the next clock.
000 State0 is the active state
001 State1 is the active state
13 –11
010 State2 is the active state
SAS2
011 State3 is the active state
100 State4 is the active state
101 State5 is the active state
110 State6 is the active state
111 State7 is the active state
Sequence 3 Active State. Two consecutive read cycles are required to know the active state. These bits
capture the active state of sequence 3 at the clock when these bits are read. The active state might be
different in the previous clock and the next clock.
000 State0 is the active state
001 State1 is the active state
16–14
010 State2 is the active state
SAS3
011 State3 is the active state
100 State4 is the active state
101 State5 is the active state
110 State6 is the active state
111 State7 is the active state
Table 1026. SS register field descriptions(Continued)
DocID027809 Rev 4
Sequence Processing Unit (SPU)
Description
1843/2058
1863
