RM0400
Field
11–15 Reserved.
VD10IE_F Interrupt Enable.
16
0 No interrupt occurs.
VD10IE_F
1 An interrupt occurs on a voltage detect event.
VD10IE_C Interrupt Enable.
17
0 No interrupt occurs.
VD10IE_C
1 An interrupt occurs on a voltage detect event.
18 Reserved.
VD10IE_IF Interrupt Enable.
19
0 No interrupt occurs.
VD10IE_IF
1 An interrupt occurs on a voltage detect event.
VD10IE_IJ Interrupt Enable.
20
0 No interrupt occurs.
VD10IE_IJ
1 An interrupt occurs on a voltage detect event.
21–23 Reserved.
VD9IE_C Interrupt Enable.
24
0 No interrupt occurs.
VD9IE_C
1 An interrupt occurs on a voltage detect event.
25–27 Reserved.
VD3IE_C Interrupt Enable.
28
0 No interrupt occurs.
VD3IE_C
1An interrupt occurs on a voltage detect event.
29–30 Reserved.
VD2IE_C Interrupt Enable.
31
0 No interrupt occurs.
VD2IE_C
1 An interrupt occurs on a voltage detect event.
54.3.1.4 Event Pending register (EPR_VD2)
This register indicates the present and past state of the voltage detect signals. If the voltage
detect event crosses the trigger threshold after the last clearing event, the flag bit is set.
Write '1' to clear the flag. Since this voltage event can only be seen when the LVD096
signals assert, these flags can only be seen in test modes that disable these PORs.
Power Management Controller digital interface (PMC_dig)
Table 900. IE_P field descriptions(Continued)
DocID027809 Rev 4
Description
1577/2058
