RM0400
Field
Sequence 1 End State.
000 State 0 is the Stop state for sequence 1
001 State 1 is the Stop state for sequence 1
010 State 2 is the Stop state for sequence 1
6–4
011 State 3 is the Stop state for sequence 1
ST2
100 State 4 is the Stop state for sequence 1
101 State 5 is the Stop state for sequence 1
110 State 6 is the Stop state for sequence 1
111 State 7 is the Stop state for sequence 1
7 Reserved. Read returns 0.
Sequence2 Enable/Disable. Once enabled, this bit is disabled at the end of the Sequence 2.
8
0 Sequence 2 is disabled
ST0
1 Sequence 2 is enabled
Sequence 2 Start State.
000State 0 is the Start state for sequence 2
001State 1 is the Start state for sequence 2
010State 2 is the Start state for sequence 2
11–9
011State 3 is the Start state for sequence 2
ST1
100State 4 is the Start state for sequence 2
101State 5 is the Start state for sequence 2
110State 6 is the Start state for sequence 2
111State 7 is the Start state for sequence 2
Sequence 2 End State.
000State 0 is the Stop state for sequence 2
001State 1 is the Stop state for sequence 2
010State 2 is the Stop state for sequence 2
14–12
011State 3 is the Stop state for sequence 2
ST2
100State 4 is the Stop state for sequence 2
101State 5 is the Stop state for sequence 2
110State 6 is the Stop state for sequence 2
111State 7 is the Stop state for sequence 2
15 Reserved. Read returns 0.
Sequence 3 Enable/Disable. Once enabled, this bit is disabled at the end of the Sequence 3.
16
0 Sequence 3 is disabled
ST0
1 Sequence 3 is enabled
Sequence 3 Start State.
000State 0 is the Start state for sequence 3
001State 1 is the Start state for sequence 3
010State 2 is the Start state for sequence 3
19–17
011State 3 is the Start state for sequence 3
ST1
100State 4 is the Start state for sequence 3
101State 5 is the Start state for sequence 3
110State 6 is the Start state for sequence 3
111State 7 is the Start state for sequence 3
Table 1024. SCTRL register field descriptions(Continued)
(1)
1
Description
