JTAG Controller (JTAGC)
59.3

Register description

This section provides a detailed description of the JTAGC block registers accessible through
the TAP interface, including data registers and the instruction register. Individual bit-level
descriptions and reset states of each register are included. These registers are not memory-
mapped and can only be accessed through the TAP.
59.3.1 Instruction register
The JTAGC block uses a 6-bit instruction register as shown in the following figure. The
instruction register allows instructions to be loaded into the block to select the test to be
performed or the test data register to be accessed or both. Instructions are shifted in through
TDI while the TAP controller is in the Shift-IR state, and latched on the falling edge of TCK in
the Update-IR state. The latched instruction value can only be changed in the Update-IR
and Test-Logic-Reset TAP controller states. Synchronous entry into the Test-Logic-Reset
state results in the IDCODE instruction being loaded on the falling edge of TCK.
Asynchronous entry into the Test-Logic-Reset state results in asynchronous loading of the
IDCODE instruction. During the Capture-IR TAP controller state, the instruction shift register
is loaded with the value 000001b, making this value the register's read value when the TAP
controller is sequenced into the Shift-IR state.
R
W
Reset:
59.3.2 Bypass register
The bypass register is a single-bit shift register path selected for serial data transfer
between TDI and TDO when the BYPASS, CLAMP, HIGHZ or reserve instructions are
active. After entry into the Capture-DR state, the single-bit shift register is set to a logic 0.
Therefore, the first bit shifted out after selecting the bypass register is always a logic 0.
59.3.3 Device identification register
The device identification (JTAG ID) register, shown in the following figure, allows the
revision number, part number, manufacturer, and design center responsible for the design of
the part to be determined through the TAP. The device identification register is selected for
serial data transfer between TDI and TDO when the IDCODE instruction is active. Entry into
the Capture-DR state while the device identification register is selected loads the IDCODE
into the shift register to be shifted out on TDO in the Shift-DR state. No action occurs in the
Update-DR state.
1734/2058
Figure 1021. 6-bit instruction register
5 4
0 0
0 0
DocID027809 Rev 4
3 2
0 0
Instruction Code
0 0
RM0400
1 0
0 1
0 1
