Table 910. Res_Vd14 Field Descriptions - STMicroelectronics SPC572L series Reference Manual

Power Management Controller digital interface (PMC_dig)
Field
0–8 Reserved.
LVD14_A reset event select—LVD on the ADC supply.
9
REE_VD14[LVD14_A] enables the reset event.
LVD14_A
0 Destructive reset
1 Functional reset
LVD14_IM reset event select—LVD on the I/O Main supply.
10
REE_VD14[LVD14_IM] enables reset event.
LVD14_IM
0 Destructive reset
1 Functional reset.
11–31 Reserved.
54.3.1.15 Voltage Supply for I/O Segments register (VSIO)
The Voltage Supply for I/O Segments (VSIO) register indicates if a particular I/O segment
uses a 3.3 V or 5.0 V supply. These bits all reset to use a 5.0 V supply.
Offset: PMC_BASE + 0x0104
0 1
R 0 0
W
Reset 0 0
16 17
R 0 0
W
Reset 0 0
Figure 949. Voltage Supply for I/O Segments register (VSIO)
Field
0–20 Reserved.
VSIO_IF control—Ethernet I/O segment supply.
21
0 The I/O segment uses a 3.3 V supply.
VSIO_IF
1 The I/O segment uses a 5.0 V supply.
VSIO_IJ control—JTAG I/O segment supply.
22
0 The I/O segment uses a 3.3 V supply.
VSIO_IJ
1 The I/O segment uses a 5.0 V supply.
23–31 Reserved.
1586/2058

Table 910. RES_VD14 field descriptions

2 3 4 5
0 0 0 0
0 0 0 0
18 19 20 21
0 0 0
0 0 0 0
Table 911. VSIO field descriptions
DocID027809 Rev 4
Description
6 7 8 9
0 0 0 0
0 0 0 0
22 23 24 25
0 0 0
0 0 0 0
Description
Access: User read/write
10 11 12 13
0 0 0 0
0 0 0 0
26 27 28 29
0 0 0 0
0 0 0 0
RM0400
14 15
0 0
0 0
30 31
0 0
0 0
