RM0400
Table 863. 'Functional' Event Short Sequence (RGM_FESS) register field descriptions(Continued)
Field
Short Sequence for oscillator failure
19
0 The reset sequence triggered by a oscillator failure event starts from PHASE1
SS_CMU_OLR
1 The reset sequence triggered by a oscillator failure event starts from PHASE3
Short Sequence for core debug reset
20
0 The reset sequence triggered by a core debug reset event starts from PHASE1
SS_CORE
1 The reset sequence triggered by a core debug reset event starts from PHASE3
Short Sequence for JTAG 'functional' reset
21
0 The reset sequence triggered by a JTAG 'functional' reset event will start from PHASE1
SS_JTAG_FUNC 1 The reset sequence triggered by a JTAG 'functional' reset event will start from PHASE3,
skipping PHASE1 and PHASE2
Short Sequence for Core Watchdog reset
22
0 The reset sequence triggered by a Core Watchdog reset event starts from PHASE1
SS_CWD
1 The reset sequence triggered by a Core Watchdog reset event starts from PHASE3
Short Sequence for System Watchdog reset
23
0 The reset sequence triggered by a System Watchdog reset event starts from PHASE1
SS_SWT
1 The reset sequence triggered by a System Watchdog reset event starts from PHASE3
24–27 Reserved
Short Sequence for software 'functional' reset
28
0 The reset sequence triggered by a software 'functional' reset event will start from PHASE1
SS_SOFT_FUNC 1 The reset sequence triggered by a software 'functional' reset event will start from PHASE3,
skipping PHASE1 and PHASE2
29 Reserved
Short Sequence for ESR1 External Reset
30
0 The reset sequence triggered by an ESR1 external reset event will start from PHASE1
SS_ESR1 1 The reset sequence triggered by an ESR1 external reset event if the reset is enabled will start
from PHASE3, skipping PHASE1 and PHASE2
Short Sequence for ESR0 External Reset
31
0 The reset sequence triggered by an ESR0 external reset event will start from PHASE1
SS_ESR0 1 The reset sequence triggered by an ESR0 external reset event if the reset is enabled will start
from PHASE3, skipping PHASE1 and PHASE2
51.3.1.10 'Functional' Reset Escalation Threshold (RGM_FRET) register
This register sets the threshold for 'functional' reset escalation to a 'destructive' reset.
Supervisor and test modes allow for read/write access, whereas read access only is allowed
in user mode.
Writing a non-zero value to the FRET field enables the 'functional' reset escalation function.
Writing any value to this register resets the 'functional' reset counter. See <Cross
Refs>Section 51.4.6, 'Functional' reset escalation for details on the 'functional' reset
escalation function.
This register is reset only on power-on and any 'destructive' reset.
Description
