Power Management Controller digital interface (PMC_dig)
Field
0–28 Reserved.
TEMP_2 temperature status flag—high temperature sensor input 2 (165 °C).
– CTL_TD[TS2IE] enables a low-voltage interrupt.
29
– REE_TD[TEMP_2] enables a system reset (which clears and negates the interrupt).
TEMP_2
– RES_TD[TEMP_2] selects functional or destructive reset.
0 Currently no occurrence, or previously cleared by writing '1'.
1 Temperature occurrence detected.
TEMP_1 temperature status flag—high temperature sensor input 1 (150 °C).
– CTL_TD[TS1IE] enables a low-voltage interrupt.
30
– REE_TD[TEMP_1] enables a system reset (which clears and negates the interrupt).
TEMP_1
– RES_TD[TEMP_1] selects functional or destructive reset.
0 Currently no occurrence, or previously cleared by writing '1'.
1 Temperature occurrence detected.
TEMP_0 temperature status flag—low temperature sensor point 0 (–40 °C).
– CTL_TD[TS0IE] enables a low-voltage interrupt.
31
– REE_TD[TEMP_0] enables a system reset (which clears and negates the interrupt).
TEMP_0
– RES_TD[TEMP_0] selects functional or destructive reset.
0 Currently no occurrence, or previously cleared by writing '1'.
1 Temperature occurrence detected.
54.3.1.18 Reset Event Enable register (REE_TD)
This Reset Event Enable register controls whether the temperature detect signal event
causes a reset. If the desired flag bit is enabled, the temperature detect event causes a
reset when the selected temperature passes the trigger event.
If the Temperature Sensor REE and RES bits are set to cause a destructive reset, then the
same REE and RES bits are also cleared by the reset.
Offset: PMC_BASE + 0x0304
0 1
R 0 0
W
Reset 0 0
16 17
R 0 0
W
Reset 0 0
1588/2058

Table 913. EPR_TD field descriptions

2 3 4 5
0 0 0 0
0 0 0 0
18 19 20 21
0 0 0 0
0 0 0 0
Figure 952. Reset Event Enable register (REE_TD)
DocID027809 Rev 4
Description
6 7 8 9
0 0 0 0
0 0 0 0
22 23 24 25
0 0 0 0
0 0 0 0
Access: User read/write
10 11 12 13
0 0 0 0
0 0 0 0
26 27 28 29
0 0 0
0 0 0 0
RM0400
14 15
0 0
0 0
30 31
0 0
