RM0400
60.6.3.5 Command Definitions
60.6.3.5.1 Store Commands
60.6.3.5.1.1 Store Miscellaneous Control Command (STMC)
STMC
Opcode Operand
00000 bbb x y
IEEE 1149.7 Compact JTAG Test Access Port Controller (CJTAG)

Table 984. Store Miscellaneous Control

bbb
000 StateCtl
001 ScanCtl
010 RdyCtl
011 DlyCtl
100 ScnFunc
101
110 Reserved
111
DocID027809 Rev 4
Store Miscellaneous Control
x y
0 0 NOP
0 1 ExitCmdLev(ECL)
1 0 Exit/Suspend (SUSPEND) = 1
1 1 ZBS Inhibit (ZBSINH) = 1
0 — SGC = y
1 — CGM = y
— — RDYC = xy
— — DLYC = xy
0 — SSDE = y
1 0 Star-4 Topology Test
1 1 Reserved
— —
— — Reserved
— —
Description
