Table 914. Ree_Td Field Descriptions - STMicroelectronics SPC572L series Reference Manual

RM0400
Field
0–28 Reserved.
TEMP_2 reset enable—high temperature sensor input 2 (165 °C).
29
RES_TD[TEMP_2] selects functional or destructive reset.
TEMP_2
0 Disabled.
1 Enabled.
TEMP_1 reset enable—high temperature sensor input 1 (150 °C).
30
RES_TD[TEMP_1] selects functional or destructive reset.
TEMP_1
0 Disabled.
1 Enabled.
TEMP_0 reset enable—low temperature sensor input 0 (–40 °C).
31
RES_TD[TEMP_0] selects functional or destructive reset.
TEMP_0
0 Disabled.
1 Enabled.
54.3.1.19 Reset Event Select register (RES_TD)
This Reset Event Select register controls whether the temperature sensor detect signal
event causes a destructive or functional reset when the corresponding Reset Event Enable
field is set.
If the Temperature Sensor REE and RES bits are set to cause a destructive reset, then the
same REE and RES bits are also cleared by the reset.
Offset: PMC_BASE + 0x0308
0 1
R 0 0
W
Reset 0 0
16 17
R 0 0
W
Reset 0 0
Field
0–28 Reserved.
TEMP_2 reset event select—high temperature sensor input 2 (165 °C).
29
REE_TD[TEMP_2] enables the reset event.
TEMP_2
0 Destructive reset.
1 Functional reset.
Power Management Controller digital interface (PMC_dig)

Table 914. REE_TD field descriptions

2 3 4 5
0 0 0 0
0 0 0 0
18 19 20 21
0 0 0 0
0 0 0 0
Figure 953. Reset Event Select register (RES_TD)
Table 915. RES_TD field descriptions
DocID027809 Rev 4
Description
6 7 8 9
0 0 0 0
0 0 0 0
22 23 24 25
0 0 0 0
0 0 0 0
Description
Access: User read/write
10 11 12 13
0 0 0 0
0 0 0 0
26 27 28 29
0 0 0
0 0 0 0
14 15
0 0
0 0
30 31
0 0
