Debug and Calibration Interface (DCI)
functions without affecting any system level functions. The DCI provides the reset signal for
all Nexus blocks. This reset is controlled using the following signals:
•
Power-on reset/Low voltage detect
•
JCOMP
•
SoC Debug_Enable signal
•
System PLL is out of lock state and not bypassed
Asserting power-on reset, negating JCOMP, or negating the Debug_Enable signal, results in
asynchronous entry into reset state. Following negation of power-on reset, the Nexus reset
signal remains asserted until the system clock achieves lock or in bypass mode, as
indicated by the system clock lock status signal, and Debug_Enable is asserted and
JCOMP is asserted. Any subsequent loss of PLL lock does not generate a Nexus reset.
This reset signal is unaffected by other sources of reset.If Debug_Enable is de-asserted by
the SoC security modules, then the DCI holds the debug and trace logic in reset. The
Debug_Enable signal is generated by security logic after functional or destructive reset
based on the device censored mode, the PASS_LOCK3[DBL] control, and the device life
cycle. If the Debug_Enable signal is asserted by the security logic, it is possible to trace
through functional resets
The following table shows how the Nexus reset is asserted/negated based on various
signals.
POR
Assert
X
X
X
Negate
58.1.3.3 System watchdog control
The DCI is also used to enable or disable the Software Watchdog Timer (SWT). The DCI
provides a single bit SWT enable signal which is used to control all SWTs in the MCU. For
this, the EVTI[0] pin is used. If the EVTI[0] pin remains high when the tool asserts JCOMP,
then the SWT is enabled. But if the tool drives the EVTI[0] pin low before asserting JCOMP
pin, then the SWT is disabled. By default the SWT is enabled and a tool has an option to
enable/disable the SWT using the EVTI[0] pin.
58.1.3.4 Break control
The DCI provides central break control among the CPUs and non-CPU debug modules
such as GTM, DMA, Watchdog and other peripherals.
There are various different input sources that provide debug requests:
1724/2058

Table 965. Nexus reset truth table

JCOMP Debug_Enable
X
Negate
X Disable
X
Assert Enable
