Intel IXP45X Developer's Manual page 946

Intel
27.6.12 Queue 32 to 63 Event 'A' Enable Register
This register contains a bit map which enables the chosen class of events (via the Event
Source Select Register) through the Event 'A' funnel. The resulting event is the field OR
of the selected event (Empty, Nearly empty, Nearly full, or Full) field ANDed with the
enable bits. Any, none, or all of the bits can form the 'A' event.
Register Name:
Block
0x0448
Base Address:
Queue Event output 'A' enable register.
Register Description:
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9
Register
Bits Name
Enable
k (0 <= k <= 31) Queue (32+k) Event Enable for 'A' Event.
Empty 'A'
27.6.13 Queue 32 to 63 Event 'B' Enable Register
This register contains a bit map which enables the chosen class of events (via the Event
Source Select Register) through the Event 'B' funnel. The resulting event is the field OR
of the selected event (Empty, Nearly empty, Nearly full, or Full) field ANDed with the
enable bits. Any, none, or all of the bits can form the 'B' event.
Register Name:
Block
0x044C
Base Address:
Queue Event output 'B' enable register.
Register Description:
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9
Register
Bits Name
Enable
k (0 <= k <= 31) Queue (32+k) Event Enable for 'B' Event.
Empty 'B'
27.6.14 Queue 32 to 63 Event 'C' Enable Register
This register contains a bit map which enables the chosen class of events (via the Event
Source Select Register) through the Event 'C' funnel. The resulting event is the field OR
of the selected event (Empty, Nearly empty, Nearly full, or Full) field ANDed with the
enable bits. Any, none, or all of the bits can form the 'C' event.
® ®
Intel IXP45X and Intel IXP46X Product Line of Network Processors
Developer's Manual
946
® ®
IXP45X and Intel IXP46X Product Line of Network Processors—AHB Queue Manager
Offset Address
Description
Offset Address
Description
QUEUPPEVA
+ 4n
Reset Value
8 7
QUEUPPEVA
QUEUPPEVB
+ 4n
Reset Value
8 7
QUEUPPEVB
Reference Number: 306262-004US
(AQM)
0x00000000
Access: (See below.)
6 5 4 3 2 1 0
Reset
Access
Value
0 RW
0x00000000
Access: (See below.)
6 5 4 3 2 1 0
Reset
Access
Value
0 RW
August 2006
