3.6.11.6.5 DBG.RX
DBG.RX is written into the RX register based on the output of the RX Write Logic. Any
data that needs to be sent from the debugger to the processor must be loaded into
DBG.RX with DBG.V set to 1. DBG.RX is loaded from DBG_SR[34:3] when the JTAG
enters the Update_DR state.
DBG.RX is written to RX following an Update_DR when the RX Write Logic enables the
RX register.
3.6.11.6.6 DBG.D
DBG.D is provided for use during high speed download. This bit is written directly to
TXRXCTRL[29]. The debugger sets DBG.D when downloading a block of code or data to
the system memory of the IXP45X/IXP46X network processors. The debug handler
then uses TXRXCTRL[29] as a branch flag to determine the end of the loop.
Using DBG.D as a branch flags eliminates the need for a loop counter in the debug
handler code. This avoids the problem were the debugger's loop counter is out of
synchronization with the debug handler's counter because of overflow conditions that
may have occurred.
3.6.11.6.7 DBG.FLUSH
DBG.FLUSH allows the debugger to flush any previous data written to RX. Setting
DBG.FLUSH clears TXRXCTRL[31].
3.6.11.7

Debug JTAG Data Register Reset Values

Upon asserting TRST, the DEBUG data register is reset. Assertion of the reset pin does
not affect the DEBUG data register.
data register. Note: these values apply for DBG_REG for SELDCSR, DBGTX and DBGRX.
Table 47.

DEBUG Data Register Reset Values

DBG_REG[0]
DBG_REG[1]
DBG_REG[33:2]
DBG_REG[34]
3.6.12

Trace Buffer

The 256-entry trace buffer provides the ability to capture control flow information to be
used for debugging an application. Two modes are supported:
• The buffer fills up completely and generates a debug exception. Then SW empties
the buffer.
• The buffer fills up and wraps around until it is disabled. Then SW empties the
buffer.
3.6.12.1

Trace Buffer CP Registers

CP14 defines three registers (see
registers are accessible using MRC, MCR, LDC and STC (CDP to any CP14 registers will
cause an undefined instruction trap). The CRn field specifies the number of the register
to access. The CRm, opcode_1, and opcode_2 fields are not used and should be set to
0.
® ®
Intel IXP45X and Intel IXP46X Product Line of Network Processors
Developer's Manual
132
® ®
IXP45X and Intel IXP46X Product Line of Network Processors—Intel XScale
Bit
unpredictable
Table 47 shows the reset and TRST values for the
TRST
0
0
unpredictable
0
Table 48) for use with the trace buffer. These CP14
®
Processor
RESET
unchanged
unchanged
unchanged
