8.5.14.8

Receive Short Packet (RSP)

The UDC uses the receive short packet bit to indicate that the received OUT packet in
the active buffer currently being read is a short packet or zero-sized packet. This bit is
updated by the UDC after the last byte is read from the active buffer and reflects the
status of the new active buffer.
If UDCCS12[RSP] is a 1 and UDCCS12[RNE] is a 0, it indicates a zero-length packet. If
a zero-length packet is present, the Intel XScale processor must not read the data
register. UDCCS12[RSP] is cleared when the next OUT packet is received.
Register Name:
0 x C800 B040
Hex Offset Address:
Register
Universal Serial Bus Device Controller Endpoint 12 Control and Status Register
Description:
Access: Read/Write
31
Bits
31:8
7
6
5
4
3
2
1
0
8.5.15

UDC Endpoint 13 Control/Status Register

The UDC Endpoint 13 Control Status Register contains four bits that are used to
operate Endpoint 13, an Isochronous IN endpoint.
August 2006
Order Number: 306262--, Revision: 004US
® ®
IXP45X and Intel IXP46X Product Line of Network
Bits
(Reserved)
X
Resets (Above)
Register
Name
Reserved for future use.
Receive short packet (read only).
RSP
1 = Short packet received and ready for reading.
Receive FIFO not empty (read-only).
RNE 0 = Receive FIFO empty.
1 = Receive FIFO not empty.
Force stall (read/write).
FST
1 = Issue STALL handshakes to OUT tokens.
Sent stall (read/write 1 to clear).
SST
1 = STALL handshake was sent.
(Reserved)
(Reserved). Always reads zero.
Receive packet complete (read/write 1 to clear).
RPC 0 = Error/status bits invalid.
1 = Receive packet has been received and error/status bits are valid.
Receive FIFO service (read-only).
RFS 0 = Receive FIFO has less than 1 data packet.
1 = Receive FIFO has 1 or more data packets.
Intel
UDCCS12
0 x 00000000
Reset Hex Value:
UDCCS12
Description
® ®
