8.5.16

UDC Endpoint 14 Control/Status Register

The UDC Endpoint 14 Control/Status Register contains six bits that are used to operate
Endpoint 14, an Isochronous OUT endpoint.
8.5.16.1

Receive FIFO Service (RFS)

The receive FIFO service bit is set if the receive FIFO has one complete data packet in it
and the packet has been error checked by the UDC. A complete packet may be
256 bytes, a short packet, or a zero packet.
UDCCS14[RFS] is not cleared until all data is read from both buffers.
