Address Mask 6; Address Registers - Intel IXP45X Developer's Manual

6.2.36

Address Mask 6

Register Name:
0x C80090B4
Hex Offset Address:
Address Mask Register #1. Sixth register of six that makes up the Address Mask. Address
Mask is used with Address for multicast address filtering. Bits set to 1 in Address Mask
Register
represent bits of the Address Register that must match the corresponding bits in incoming
Description:
destination addresses for packets to be accepted.
Access: Read/Write.
31
Bits
47:0
6.2.37

Address Registers

Six registers make up the 48-bit Address:
• Address[47:40] — Address 1
• Address[39:32] — Address 2
• Address[31:24] — Address 3
• Address[23:16] — Address 4
• Address[15:8] — Address 5
• Address[7:0] — Address 6
Example: Address is 00-A0-24-D1-7F-02
• Address 1 = 0x00
• Address 2 = 0xA0
• Address 3 = 0x24
• Address 4 = 0xD1
• Address 5 = 0x7F
• Address 6 = 0x02
The detailed bit descriptions follow the six registers' bit maps.
® ®
