Table 105. Ethernet MAC on NPE A (Sheet 2 of 2)
Address
0xC800 C0CC
0xC800 C0D0
0xC800 C0D4
0xC800 C0E0
0xC800 C0F0
0xC800 C0F4
0xC800 C0F8
0xC800 C0FC
0xC800 C100
0xC800 C104
0xC800 C1FC
† The MDI interface on NPE-A is inactive. All external PHYs are configured via NPE-B.
6.2.6

Ethernet MAC on NPE C

Table 106. Ethernet MAC on NPE C (Sheet 1 of 2)
Address
0xC800 A000
0xC800 A004
0xC800 A010
0xC800 A014
0xC800 A020
0xC800 A030
0xC800 A038
0xC800 A040
0xC800 A050
0xC800 A054
0xC800 A060
0xC800 A064
0xC800 A070
0xC800 A080
0xC800 A084
August 2006
Order Number: 306262-004US
®
IXP46X Product Line of Network Processors
Description
Address 4
Address 5
Address 6
Threshold For Internal Clock
Unicast Address 1
Unicast Address 2
Unicast Address 3
Unicast Address 4
Unicast Address 5
Unicast Address 6
Core Control
Description
Transmit Control 1
Transmit Control 2
Receive Control 1
Receive Control 2
Random Seed
Threshold For Partial Empty
Threshold For Partial Full
Buffer Size For Transmit
Transmit Single Deferral Parameters
Receive Deferral Parameters
Transmit Two Part Deferral Parameters 1
Transmit Two Part Deferral Parameters 2
Slot Time
†
MDIO Command 1
†
MDIO Command 2
®
