DBR0 is a dedicated data address breakpoint register. DBR1 can be programmed for
one of two operations:
• Data address mask
• Second data address breakpoint
The DBCON register controls the functionality of DBR1, as well as the enables for both
DBRs. DBCON also controls what type of memory access to break on.
Table 39.

Data Breakpoint Controls Register (DBCON)

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9
reset value: 0x00000000
Bits
31:9
8
7:4
3:2
1:0
When DBR1 is programmed as a data address mask, it is used in conjunction with the
address in DBR0. The bits set in DBR1 are ignored by the processor when comparing
the address of a memory access with the address in DBR0. Using DBR1 as a data
address mask allows a range of addresses to generate a data breakpoint. When DBR1
is selected as a data address mask, it is unaffected by the E1 field of DBCON. The mask
is used only when DBR0 is enabled.
When DBR1 is programmed as a second data address breakpoint, it functions
independently of DBR0. In this case, the DBCON.E1 controls DBR1.
A data breakpoint is triggered if the memory access matches the access type and the
address of any byte within the memory access matches the address in DBRx. For
example, LDR triggers a breakpoint if DBCON.E0 is 0b10 or 0b11, and the address of
any of the 4 bytes accessed by the load matches the address in DBR0.
The processor does not trigger data breakpoints for the PLD instruction or any CP15,
register 7, 8, 9, or 10 functions. Any other type of memory access can trigger a data
breakpoint. For data breakpoint purposes the SWP and SWPB instructions are treated
as stores - they will not cause a data breakpoint if the breakpoint is set up to break on
loads only and an address match occurs.
On unaligned memory accesses, breakpoint address comparison is done on a word-
aligned address (aligned down to word boundary).
August 2006
Order Number: 306262-004US
® ®
IXP45X and Intel IXP46X Product Line of Network Processors
Access
Read-as-Zero / Write-ignored
Read / Write
Read-as-Zero / Write-ignored
Read / Write
Read / Write
Intel
Reserved
DBR1 Mode (M) -
0: DBR1 = Data Address Breakpoint
1: DBR1 = Data Address Mask
Reserved
DBR1 Enable (E1) -
When DBR1 = Data Address Breakpoint
0b00: DBR1 disabled
0b01: DBR1 enabled, Store only
0b10: DBR1 enabled, Any data access, load or store
0b11: DBR1 enabled, Load only
When DBR1 = Data Address Mask this field has no effect
DBR0 Enable (E0) -
0b00: DBR0 disabled
0b01: DBR0 enabled, Store only
0b10: DBR0 enabled, Any data access, load or store
0b11: DBR0 enabled, Load only
® ®
IXP45X and Intel IXP46X Product Line of Network Processors
8 7 6 5 4 3 2
M E1
Description
Developer's Manual
1 0
E0
