Bits
31:8
7:0
8.5.25

UDC Byte Count Register 4

The Byte-Count Register maintains the remaining byte count in the active buffer of out
Endpoint 4.
8.5.25.1

Endpoint 4 Byte Count (BC[7:0])

The byte count is updated after each byte is read. When software receives an interrupt
that indicates the endpoint has data, it can read the byte count register to determine
the number of bytes that remain to be read.
The number of bytes that remain in the input buffer is equal to the byte count +1.
Register Name:
0 x C800B06C
Hex Offset Address:
Register
Universal Serial Bus Device Endpoint 4 Byte Count
Description:
Access: Read-Only
31
Bits
31:8
7:0
8.5.26

UDC Byte Count Register 7

The Byte-Count Register maintains the remaining byte count in the active buffer of out
endpoint 7.
®
®
Intel
IXP45X and Intel
IXP46X Product Line of Network Processors
Developer's Manual
338
®
®
Intel
IXP45X and Intel
Register
Name
(Reserved)
Byte Count (read-only).
BC
Number of bytes in the FIFO is Byte Count plus 1 (BC+1)
(Reserved)
X
Resets (Above)
Register
Name
(Reserved)
Byte Count (read-only).
BC
Number of bytes in the FIFO is Byte Count plus 1 (BC+1).
IXP46X Product Line of Network Processors—USB 1.1 Device
UBCR2
Description
UBCR4
0x00000000
Reset Hex Value:
Bits
UBCR4
Description
Controller
(UBCR4)
8
7
BC[7:0]
0
0
0
0
0
0
0
(UBCR7)
August 2006
Order Number: 306262-004US
0
0
