Random Number Generator—Intel
Processors
24.0

Random Number Generator

24.1

Theory of Operation

The Random Number Generator (RNG) unit provides a digital, random-number-
generation capability.
The Random Number Generator (RNG) produces a series of random numbers for use in,
among other things, key generation. The only method of access to these numbers is via
a read from the random number FIFO. No other visibility is provided into the workings
of this unit by the processor, nor is their any method of control or parameterization by
any external method.
24.2 Detailed Register Descriptions
Table 285.

Register Legend

Attribute
RV
PR
RS
RW
RW1C
Table 286.

Register Summary

Block Offset
Address Address
0x7000 _2100
August 2006
Order Number: 306262-004US
®
IXP45X and Intel
Legend
Reserved
Preserved
Read/Set
Read/Write
Normal Read
Write '1' to clear
Register Name
FIFO containing random numbers generated by the
RNG_FIFO RNG. After a number is read, it is removed from the
stack, and the next number is made available
®
IXP46X Product Line of Network
Attribute Legend
RC Read Clear
RO Read Only
WO Write Only
NA Not Accessible
Normal Read
RW1S
Write '1' to set
Description
® ®
Intel IXP45X and Intel IXP46X Product Line of Network Processors
Page
Reset Value
Number
Unknown
912
Developer's Manual
911
