66.4.9

Nexus Overrun Control (OVCR) register

The Nexus Overrun Control register controls Nexus behavior as the internal message
queues fill up. Response options include suppressing selected message types, or stalling
processor instruction execution.
0
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
Table 1090. WMSK field descriptions
Messaging
0 SPEN
Nexus Reg# 0x32; DCR: 410; Read/Write; Reset: 0x0
Figure 1143. Nexus Overrun Control (OVCR) register
DocID027809 Rev 4
e200z215An3 Nexus 3 Module
Description
No Watchpoints enabled for Watchpoint Trace
Watchpoint #0 enabled for WTM
Watchpoint #1 enabled for WTM
Watchpoint #2 enabled for WTM
Watchpoint #3 enabled for WTM
Watchpoint #4 enabled for WTM
Watchpoint #5 enabled for WTM
Watchpoint #6 enabled for WTM
Watchpoint #7 enabled for WTM
Watchpoint #8 enabled for WTM
Watchpoint #9 enabled for WTM
Watchpoint #10 enabled for WTM
Watchpoint #11 enabled for WTM
Watchpoint #12 enabled for WTM
Watchpoint #13 enabled for WTM
Watchpoint #14 enabled for WTM
Watchpoint #15 enabled for WTM
Watchpoint #16 enabled for WTM
Watchpoint #17 enabled for WTM
Watchpoint #18 enabled for WTM
Watchpoint #19 enabled for WTM
Watchpoint #20 enabled for WTM
Watchpoint #21 enabled for WTM
Watchpoint #22 enabled for WTM
Watchpoint #23 enabled for WTM
Watchpoint #24 enabled for WTM
Watchpoint #25 enabled for WTM
Watchpoint #26 enabled for WTM
Watchpoint #27 enabled for WTM
Watchpoint #28 enabled for WTM
Watchpoint #29 enabled for WTM
Watchpoint #30 enabled for WTM
Watchpoint #31 enabled for WTM
