Table 1081. Dc2 Field Descriptions - STMicroelectronics SPC572L series Reference Manual

e200z215An3 Nexus 3 Module
Bits Name
31:28 WEVTO[3]C
27:24 WEVTO[2]C
23:20 WEVTO[1]C
1924/2058

Table 1081. DC2 field descriptions

Watchpoint Event Out 3 Configuration
0000 — No Watchpoints #0–14 trigger nex_wevto[3]
0001 — Watchpoint #0 triggers nex_wevto[3]
0010 — Watchpoint #1 triggers nex_wevto[3]
0011 — Watchpoint #2 triggers nex_wevto[3]
0100 — Watchpoint #3 triggers nex_wevto[3]
0101 — Watchpoint #4 triggers nex_wevto[3]
0110 — Watchpoint #5 triggers nex_wevto[3]
0111 — Watchpoint #6 triggers nex_wevto[3]
1000 — Watchpoint #7 triggers nex_wevto[3]
1001 — Watchpoint #8 triggers nex_wevto[3]
1010 — Watchpoint #9 triggers nex_wevto[3]
1011 — Watchpoint #10 triggers nex_wevto[3]
1100 — Watchpoint #11 triggers nex_wevto[3]
1101 — Watchpoint #12 triggers nex_wevto[3]
1110 — Watchpoint #13 triggers nex_wevto[3]
1111 — Watchpoint #14 triggers nex_wevto[3]
Watchpoint Event Out 2 Configuration
0000 — No Watchpoints #0–14 trigger nex_wevto[2]
0001 — Watchpoint #0 triggers nex_wevto[2]
0010 — Watchpoint #1 triggers nex_wevto[2]
0011 — Watchpoint #2 triggers nex_wevto[2]
0100 — Watchpoint #3 triggers nex_wevto[2]
0101 — Watchpoint #4 triggers nex_wevto[2]
0110 — Watchpoint #5 triggers nex_wevto[2]
0111 — Watchpoint #6 triggers nex_wevto[2]
1000 — Watchpoint #7 triggers nex_wevto[2]
1001 — Watchpoint #8 triggers nex_wevto[2]
1010 — Watchpoint #9 triggers nex_wevto[2]
1011 — Watchpoint #10 triggers nex_wevto[2]
1100 — Watchpoint #11 triggers nex_wevto[2]
1101 — Watchpoint #12 triggers nex_wevto[2]
1110 — Watchpoint #13 triggers nex_wevto[2]
1111 — Watchpoint #14 triggers nex_wevto[2]
Watchpoint Event Out 1 Configuration
0000 — No Watchpoints #0–14 trigger nex_wevto[1]
0001 — Watchpoint #0 triggers nex_wevto[1]
0010 — Watchpoint #1 triggers nex_wevto[1]
0011 — Watchpoint #2 triggers nex_wevto[1]
0100 — Watchpoint #3 triggers nex_wevto[1]
0101 — Watchpoint #4 triggers nex_wevto[1]
0110 — Watchpoint #5 triggers nex_wevto[1]
0111 — Watchpoint #6 triggers nex_wevto[1]
1000 — Watchpoint #7 triggers nex_wevto[1]
1001 — Watchpoint #8 triggers nex_wevto[1]
1010 — Watchpoint #9 triggers nex_wevto[1]
1011 — Watchpoint #10 triggers nex_wevto[1]
1100 — Watchpoint #11 triggers nex_wevto[1]
1101 — Watchpoint #12 triggers nex_wevto[1]
1110 — Watchpoint #13 triggers nex_wevto[1]
1111 — Watchpoint #14 triggers nex_wevto[1]
DocID027809 Rev 4
Description
RM0400
