Register Descriptions - STMicroelectronics SPC572L series Reference Manual

Password and Device Security Module (PASS)
Offset
0x0124 Lock 1 Status Register (LOCK1_PG2)
0x0128 Lock 2 Status Register (LOCK2_PG2)
0x012C Lock 3 Status Register (LOCK3_PG2)
0x0130 Lock 0 Status Register (LOCK0_PG3)
0x0134 Lock 1 Status Register (LOCK1_PG3)
0x0138 Lock 2 Status Register (LOCK2_PG3)
0x013C Lock 3 Status Register (LOCK3_PG3)
1. Reset value depends on life cycle status
2. Reset value depends on password group lock state
Note: Non-implemented registers generate bus aborts if enabled by the SOC.
68.2.1

Register descriptions

The following registers are available in the PASS. The shaded bits are reserved for future
use. For future compatibility, only write '0' to these bits; they always read '0'.
68.2.1.1 Life Cycle Status register (LCSTAT)
The Life Cycle Status Register reflects the production status and censorship status of the
device. It is possible to mature the device (move the device life cycle forward), but never to
revert the life cycle to an earlier state.
The reset value of the LCSTAT register LIFE field derives from an external life cycle
management module (like SSCM). It is a 3-bit life cycle. This register simply displays the life
cycle input from external blocks.
Offset 0x0000
0 1
R CNS JUN
W
(1)
Reset x 0
16 17 18
R 0 0
W
Reset 0 0
1. Reset value depends on the Censorship DCF client
PASS_LCSTAT register functions are as shown in
1996/2058
Table 1127. PASS memory map(Continued)
Register
2 3 4 5
0 0 0 0
0 0 0 0
19 20 21
0 0 0 0
0 0 0 0
Figure 1198. Life Cycle Status register (LCSTAT)
DocID027809 Rev 4
Access Reset Value
R/W 0xx000_xxxx
R/W 0xxxxx_xxxx
R/W 0xx0xx_xxxx
Password Group 3
R/W 0xxxxx_xxxx
R/W 0xx000_xxxx
R/W 0xxxxx_xxxx
R/W 0xx0xx_xxxx
6 7 8 9
0 0 0 0
0 0 0 0
22 23 24 25
0 0 0 0
0 0 0 0
Table
DCF Client
Address Section/Page
(ADDR[14:0])
0x0124 68.2.1.6/2001
2
0x0128 68.2.1.7/2002
2
0x012C 68.2.1.8/2003
2
0x0130 68.2.1.5/1999
0x0134 68.2.1.6/2001
2
0x0138 68.2.1.7/2002
2
0x013C 68.2.1.8/2003
Access: Software Read
10 11 12 13
0 0 0 0
0 0 0 0
26 27 28 29
0 0 0
0 0 0 1
1128.
RM0400
14 15
0 0
0 0
30 31
LIFE
1 1
