Nexus Aurora Router (NAR)
suppress or wake clients individually or the entire NAR. All receive queues can be
suppressed on the occurrence of a selected trigger, or the full NAR can be brought out of
suppress mode upon the occurrence of the appropriate trigger. A trigger can also be
programmed to toggle one or more clients between the suppressed and active states. Each
Suppress Trigger Control Register, shown in the following figure, is associated with one of
the triggers, and are used to determine the action taken, if any, upon the assertion of that
trigger. The suppress triggers are connected to the Sequence Processing Unit (SPU) action
unit.
Register index: 7–A
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9
R 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
GST
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 1119. Suppress trigger control registers (NAR_STCR1–4)
The NAR_STCR are described in the following table. The set of clients connected to the
NAR is device specific. For a list of the clients that are connected to the NAR and their
corresponding NAR client index for the local suppress trigger, see the Calibration and
Debug configuration chapter which describes how the modules are configured.
Field
Global Suppress Trigger.
31
0 The associated trigger cannot cause NAR to enter global suppress mode
GST
1 The associated trigger is enabled for global suppress mode
29–16 Reserved
Local Suppress Trigger.
0000000000000000The associated trigger is disabled for local suppress mode for all clients
xxxxxxxxxxxxxxx1Trigger is enabled for Client 1 local suppress
xxxxxxxxxxxxxx1xTrigger is enabled for Client 2 local suppress
xxxxxxxxxxxxx1xxTrigger is enabled for Client 3 local suppress
xxxxxxxxxxxx1xxxTrigger is enabled for Client 4 local suppress
xxxxxxxxxxx1xxxxTrigger is enabled for Client 5 local suppress
xxxxxxxxxx1xxxxxTrigger is enabled for Client 6 local suppress
xxxxxxxxx1xxxxxxTrigger is enabled for Client 7 local suppress
15–0
xxxxxxxx1xxxxxxxTrigger is enabled for Client 8 local suppress
LST
xxxxxxx1xxxxxxxxTrigger is enabled for Client 9 local suppress
xxxxxx1xxxxxxxxxTrigger is enabled for Client 10 local suppress
xxxxx1xxxxxxxxxxTrigger is enabled for Client 11 local suppress
xxxx1xxxxxxxxxxxTrigger is enabled for Client 12 local suppress
xxx1xxxxxxxxxxxxTrigger is enabled for Client 13 local suppress
xx1xxxxxxxxxxxxxTrigger is enabled for Client 14 local suppress
x1xxxxxxxxxxxxxxTrigger is enabled for Client 15 local suppress
1xxxxxxxxxxxxxxxTrigger is enabled for Client 16 local suppress
All other optionsReserved
1884/2058

Table 1057. NAR_STCR field descriptions

DocID027809 Rev 4
Description
RM0400
8 7 6 5 4 3 2 1 0
LST
