Table 1082. Dc3 Field Descriptions - STMicroelectronics SPC572L series Reference Manual

e200z215An3 Nexus 3 Module
Bits Name
31:28 WEVTO[3]C
27:24 WEVTO[2]C
23:20 WEVTO[1]C
1926/2058

Table 1082. DC3 field descriptions

Watchpoint Event Out 3 Configuration
0000 No Watchpoints #15–#26 trigger nex_wevto[3]
0001 Watchpoint #15 triggers nex_wevto[3]
0010 Watchpoint #16 triggers nex_wevto[3]
0011 Watchpoint #17 triggers nex_wevto[3]
0100 Watchpoint #18 triggers nex_wevto[3]
0101 Watchpoint #19 triggers nex_wevto[3]
0110 Watchpoint #20 triggers nex_wevto[3]
0111 Watchpoint #21 triggers nex_wevto[3]
1000 Watchpoint #22 triggers nex_wevto[3]
1001 Watchpoint #23 triggers nex_wevto[3]
1010 Watchpoint #24 triggers nex_wevto[3]
1011 Watchpoint #25 triggers nex_wevto[3]
1100 Watchpoint #26 triggers nex_wevto[3]
11x1 Reserved
Watchpoint Event Out 2 Configuration
0000 No Watchpoints #15–#26 trigger nex_wevto[2]
0001 Watchpoint #15 triggers nex_wevto[2]
0010 Watchpoint #16 triggers nex_wevto[2]
0011 Watchpoint #17 triggers nex_wevto[2]
0100 Watchpoint #18 triggers nex_wevto[2]
0101 Watchpoint #19 triggers nex_wevto[2]
0110 Watchpoint #20 triggers nex_wevto[2]
0111 Watchpoint #21 triggers nex_wevto[2]
1000 Watchpoint #22 triggers nex_wevto[2]
1001 Watchpoint #23 triggers nex_wevto[2]
1010 Watchpoint #24 triggers nex_wevto[2]
1011 Watchpoint #25 triggers nex_wevto[2]
1100 Watchpoint #26 triggers nex_wevto[2]
11x1 Reserved
Watchpoint Event Out 1 Configuration
0000 No Watchpoints #15–#29 trigger nex_wevto[1]
0001 Watchpoint #15 triggers nex_wevto[1]
0010 Watchpoint #16 triggers nex_wevto[1]
0011 Watchpoint #17 triggers nex_wevto[1]
0100 Watchpoint #18 triggers nex_wevto[1]
0101 Watchpoint #19 triggers nex_wevto[1]
0110 Watchpoint #20 triggers nex_wevto[1]
0111 Watchpoint #21 triggers nex_wevto[1]
1000 Watchpoint #22 triggers nex_wevto[1]
1001 Watchpoint #23 triggers nex_wevto[1]
1010 Watchpoint #24 triggers nex_wevto[1]
1011 Watchpoint #25 triggers nex_wevto[1]
1100 Watchpoint #26 triggers nex_wevto[1]
1101 Watchpoint #27 triggers nex_wevto[1]
1110 Watchpoint #28 triggers nex_wevto[1]
1111 Watchpoint #29 triggers nex_wevto[1]
