RM0400
Bits Name
31:30 — Reserved for future functionality (read as 0)
Data Trace Start Trigger Control
000000000000000000000000000000
xxxxxxxxxxxxxxxxxxxxxxxxxxxxx1
xxxxxxxxxxxxxxxxxxxxxxxxxxxx1x
xxxxxxxxxxxxxxxxxxxxxxxxxxx1xx
xxxxxxxxxxxxxxxxxxxxxxxxxx1xxx
xxxxxxxxxxxxxxxxxxxxxxxxx1xxxx
xxxxxxxxxxxxxxxxxxxxxxxx1xxxxx
xxxxxxxxxxxxxxxxxxxxxxx1xxxxxx
xxxxxxxxxxxxxxxxxxxxxx1xxxxxxx
xxxxxxxxxxxxxxxxxxxxx1xxxxxxxx
xxxxxxxxxxxxxxxxxxxx1xxxxxxxxx
xxxxxxxxxxxxxxxxxxx1xxxxxxxxxx
xxxxxxxxxxxxxxxxxx1xxxxxxxxxxx
xxxxxxxxxxxxxxxxx1xxxxxxxxxxxx
xxxxxxxxxxxxxxxx1xxxxxxxxxxxxx
29:0 DTST
xxxxxxxxxxxxxxx1xxxxxxxxxxxxxx
xxxxxxxxxxxxxx1xxxxxxxxxxxxxxx
xxxxxxxxxxxxx1xxxxxxxxxxxxxxxx
xxxxxxxxxxxx1xxxxxxxxxxxxxxxxx
xxxxxxxxxxx1xxxxxxxxxxxxxxxxxx
xxxxxxxxxx1xxxxxxxxxxxxxxxxxxx
xxxxxxxxx1xxxxxxxxxxxxxxxxxxxx
xxxxxxxx1xxxxxxxxxxxxxxxxxxxxx
xxxxxxx1xxxxxxxxxxxxxxxxxxxxxx
xxxxxx1xxxxxxxxxxxxxxxxxxxxxxx
xxxxx1xxxxxxxxxxxxxxxxxxxxxxxx
xxxx1xxxxxxxxxxxxxxxxxxxxxxxxx
xxx1xxxxxxxxxxxxxxxxxxxxxxxxxx
xx1xxxxxxxxxxxxxxxxxxxxxxxxxxx
x1xxxxxxxxxxxxxxxxxxxxxxxxxxxx
1xxxxxxxxxxxxxxxxxxxxxxxxxxxxx
For extended Data Trace end trigger control, the DTETC register is used.
0
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
Figure 1141. Data Trace End Trigger Control (DTETC) register
The following table details the DTETC register fields.

Table 1088. DTSTC field descriptions

Nexus Reg# 038; DCR: 415; Read/Write; Reset: 0x0
DocID027809 Rev 4
e200z215An3 Nexus 3 Module
Description
Trigger disabled
Use Watchpoint #0
Use Watchpoint #1
Use Watchpoint #2
Use Watchpoint #3
Use Watchpoint #4
Use Watchpoint #5
Use Watchpoint #6
Use Watchpoint #7
Use Watchpoint #8
Use Watchpoint #9
Use Watchpoint #10
Use Watchpoint #11
Use Watchpoint #12
Use Watchpoint #13
Use Watchpoint #14
Use Watchpoint #15
Use Watchpoint #16
Use Watchpoint #17
Use Watchpoint #18
Use Watchpoint #19
Use Watchpoint #20
Use Watchpoint #21
Use Watchpoint #22
Use Watchpoint #23
Use Watchpoint #24
Use Watchpoint #25
Use Watchpoint #26
Use Watchpoint #27
Use Watchpoint #28
Use Watchpoint #29
DTET
9 8 7 6 5 4 3 2
1933/2058
1 0
