Octo-SPI interface (OCTOSPI)
19.6.12 OCTOSPI polling status match register (OCTOSPI_PSMAR)
Address offset: 0x0088
Reset value: 0x0000 0000
31 30 29 28
rw rw rw rw
15 14 13 12
rw rw rw rw
Bits 31:0 MATCH[31: 0]: Status match
Value to be compared with the masked status register to get a match
This field can be written only when BUSY = 0.
19.6.13 OCTOSPI polling interval register (OCTOSPI_PIR)
Address offset: 0x0090
Reset value: 0x0000 0000
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
rw rw rw rw
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 INTERVAL[15: 0]: Polling interval
Number of CLK cycle between a read during the automatic polling phases
This field can be written only when BUSY = 0.
19.6.14 OCTOSPI communication configuration register (OCTOSPI_CCR)
Address offset: 0x0100
Reset value: 0x0000 0000
31 30 29 28
SIOO Res. DQSE Res.
rw rw
15 14 13 12
Res. Res. ADSIZE[1:0]
rw rw
