ST STM32L4+ Series Reference Manual page 101

RM0432
Table 2. STM32L4P5xx and STM32L4Q5xx memory map and peripheral register boundary
Bus Boundary address
0x5006 2C00 - 0x5FFF FFFF
0x5006 2400 - 0x5006 27FF
0x5006 2800 - 0x5006 2BFF
0x5006 2000 - 0x5006 23FF
0x5006 1C00 - 0x5006 1FFF
0x5006 0C00 - 0x5006 1BFF
0x5006 0800 - 0x5006 0BFF
0x5006 0400 - 0x5006 07FF
0x5006 0000 - 0x5006 03FF
0x5005 E000 - 0x5005 FFFF
0x5005 0800 - 0x5005 DFFF
0x5005 0400 - 0x5005 07FF
AHB2
0x5005 0000 - 0x5005 03FF
0x5004 0400 - 0x5004 FFFF
0x5004 0000 - 0x5004 03FF
0x5000 0000 - 0x5003 FFFF
0x4800 2400 - 0x4FFF FFFF
0x4800 2000 - 0x4800 23FF
0x4800 1C00 - 0x4800 1FFF
0x4800 1800 - 0x4800 1BFF
0x4800 1400 - 0x4800 17FF
0x4800 1000 - 0x4800 13FF
0x4800 0C00 - 0x4800 0FFF
0x4800 0800 - 0x4800 0BFF
0x4800 0400 - 0x4800 07FF
0x4800 0000 - 0x4800 03FF
addresses (continued)
Size
Peripheral
(bytes)
~260 MB Reserved
1 KB SDMMC1
1 KB SDMMC2
1 KB Reserved
1 KB OCTOSPIM
4 KB Reserved
1 KB RNG
1 KB HASH
1 KB AES
8 KB PKA + RAM
54 KB Reserved
1 KB PSSI
1 KB DCMI
62 KB Reserved
1 KB ADC1 + ADC2
16 KB OTG_FS
~127 MB Reserved
1 KB GPIOI
1 KB GPIOH
1 KB GPIOG
1 KB GPIOF
1 KB GPIOE
1 KB GPIOD
1 KB GPIOC
1 KB GPIOB
1 KB GPIOA
RM0432 Rev 6
Peripheral register map
-
Section 54.9.20: SDMMC register
map
Section 54.9.20: SDMMC register
map
-
Section 20.5.3: OCTOSPIM register
map
-
Section 32.7.5: RNG register map
Section 35.7.8: HASH register map
Section 34.7.18: AES register map
Section 36.7.5: PKA register map
and reset values
-
Section 25.5.8: PSSI register map
Section 24.5.12: DCMI register map
-
Section 21.8: ADC register map on
page 721
Section 56.15.57: OTG_FS register
map
-
Section 8.4.12: GPIO register map
Section 8.4.12: GPIO register map
Section 8.4.12: GPIO register map
Section 8.4.12: GPIO register map
Section 8.4.12: GPIO register map
Section 8.4.12: GPIO register map
Section 8.4.12: GPIO register map
Section 8.4.12: GPIO register map
Section 8.4.12: GPIO register map
101/2301
