ST STM32L4+ Series Reference Manual page 777

RM0432
Table 162. Data storage in YCbCr progressive video format - Y extraction mode
Byte address
Half resolution image extraction
This is a modification of the previous reception modes, being applicable to monochrome,
RGB or Y extraction modes.
This mode is used to only store a half resolution image. It is selected through OELS and
LSM control bits.
24.4 DCMI interrupts
Five interrupts are generated. All interrupts are maskable by software. The global interrupt
(DCMI_IT) is the OR of all the individual interrupts. The table below gives the list of all
interrupts.
Interrupt
Interrupt event
acronym
End of line
End of frame capture
Overrun of data reception
DCMI_IT
Synchronization frame
Detection of an error in the
embedded
synchronization frame
31:24
0 Y n + 3
4 Y n + 7
Table 163. DCMI interrupts
Event flag
LINE_RIS
FRAME_RIS
OVR_RIS
VSYNC_RIS
ERR_RIS
detection
23:16
Y n + 2
Y n + 6
Enable
control bit
LINE_IE
FRAME_IE
OVR_IE
VSYNC_IE
ERR_IE
RM0432 Rev 6
Digital camera interface (DCMI)
15:8
Y n + 1
Y n + 5
Exits
Interrupt clear
Sleep
method
mode
Set LINE_ISC Yes
Set FRAME_ISC Yes
Set OVR_ISC Yes
Set VSYNC_ISC Yes
Set ERR_ISC Yes
7:0
Y n
Y n + 4
Exists
Stop and
Standby
modes
No
No
No
No
No
777/2301
