Analog-to-digital converters (ADC)
Figure 123. AUTODLY=1, regular HW conversions interrupted by injected conversions
Regular
trigger
ADC state
RDY CH1
regular
EOC
EOS
ADC_DR
read access
ADC_DR
Injected
trigger
JEOS
ADC_JDR1
ADC_JDR2
by s/w
1. AUTDLY=1
2. Regular configuration: EXTEN[1:0]=01 (HW trigger), CONT=0, DISCEN=0, CHANNELS = 1, 2, 3
3. Injected configuration: JEXTEN[1:0]=01 (HW Trigger), JDISCEN=0, CHANNELS = 5,6
658/2301
(DISCEN=0; JDISCEN=0)
Ignored
DLY CH2 DLY
regular
DLY (CH1)
DLY (CH2)
D1
by h/w
RM0432 Rev 6
Not ignored
(occurs during injected sequence)
CH5 CH6 CH3
regular injected
injected
DLY (CH3)
D2
Ignored
DLY (inj)
Indicative timings
