21.6.20 ADC Analog Watchdog 3 Configuration Register (ADC_AWD3CR)
Address offset: 0xA4
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
rw rw rw
Bits 31:19 Reserved, must be kept at reset value.
Bits 18:0 AWD3CH[18:0]: Analog watchdog 3 channel selection
These bits are set and cleared by software. They enable and select the input channels to be guarded
by the analog watchdog 3.
AWD3CH[i] = 0: ADC analog input channel i is not monitored by AWD3
AWD3CH[i] = 1: ADC analog input channel i is monitored by AWD3
When AWD3CH[18:0] = 000..0, the analog Watchdog 3 is disabled
Note: The channels selected by AWD3CH must be also selected into the SQRi or JSQRi registers.
The software is allowed to write these bits only when ADSTART=0 and JADSTART=0 (which
ensures that no conversion is ongoing).
Some channels are not connected physically and must not be selected for the analog
watchdog.
21.6.21 ADC Differential mode Selection Register (ADC_DIFSEL)
Address offset: 0xB0
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
rw rw rw
Bits 31:19 Reserved, must be kept at reset value.
Bits 18:0 DIFSEL[18:0]: Differential mode for channels 18 to 0.
These bits are set and cleared by software. They allow to select if a channel is configured as single-
ended or differential mode.
DIFSEL[i] = 0: ADC analog input channel is configured in single ended mode
DIFSEL[i] = 1: ADC analog input channel i is configured in differential mode
Note: The DIFSEL bits corresponding to channels that are either connected to a single-ended I/O port
or to an internal channel must be kept their reset value (single-ended input mode).
The software is allowed to write these bits only when the ADC is disabled (ADCAL=0,
JADSTART=0, JADSTP=0, ADSTART=0, ADSTP=0, ADDIS=0 and ADEN=0).
28 27 26 25
Res. Res. Res.
12 11 10 9
rw rw rw rw
28 27 26 25
Res. Res. Res.
12 11 10 9
rw rw rw rw
24 23 22
Res. Res. Res.
8 7 6
AWD3CH[15:0]
rw rw rw
24 23 22
Res. Res. Res.
8 7 6
DIFSEL[15:0]
rw rw rw
RM0432 Rev 6
Analog-to-digital converters (ADC)
21 20 19 18
Res. Res. Res.
rw
5 4 3 2
rw rw rw rw
21 20 19 18
Res. Res. Res.
rw
5 4 3 2
rw rw rw rw
17 16
AWD3CH[18:16]
rw rw
1 0
rw rw
17 16
DIFSEL[18:16]
rw rw
1 0
rw r
