Bit 6 CKABEN: Clock absence detector enable on channel y
0: Clock absence detector disabled on channel y
1: Clock absence detector enabled on channel y
Bit 5 SCDEN: Short-circuit detector enable on channel y
0: Input channel y will not be guarded by the short-circuit detector
1: Input channel y will be continuously guarded by the short-circuit detector
Bit 4 Reserved, must be kept at reset value.
Bits 3:2 SPICKSEL[1:0]: SPI clock select for channel y
0: clock coming from external CKINy input - sampling point according SITP[1:0]
1: clock coming from internal CKOUT output - sampling point according SITP[1:0]
2: clock coming from internal CKOUT - sampling point on each second CKOUT falling edge.
For connection to external Σ∆ modulator which divides its clock input (from CKOUT) by 2 to
generate its output serial communication clock (and this output clock change is active on each
clock input rising edge).
3: clock coming from internal CKOUT output - sampling point on each second CKOUT rising edge.
For connection to external Σ∆ modulator which divides its clock input (from CKOUT) by 2 to
generate its output serial communication clock (and this output clock change is active on each
clock input falling edge).
This value can be modified only when CHEN=0 (in DFSDM_CHyCFGR1 register).
Bits 1:0 SITP[1:0]: Serial interface type for channel y
00: SPI with rising edge to strobe data
01: SPI with falling edge to strobe data
10: Manchester coded input on DATINy pin: rising edge = logic 0, falling edge = logic 1
11: Manchester coded input on DATINy pin: rising edge = logic 1, falling edge = logic 0
This value can only be modified when CHEN=0 (in DFSDM_CHyCFGR1 register).
28.7.2 DFSDM channel y configuration register (DFSDM_CHyCFGR2)
This register specifies the parameters used by channel y.
Address offset: 0x04 + 0x20 * y, (y = 0 to 7)
Reset value: 0x0000 0000
31 30 29 28
rw rw rw rw
15 14 13 12
OFFSET[7:0]
rw rw rw rw
862/2301
27 26 25 24
OFFSET[23:8]
rw rw rw rw
11 10 9 8
rw rw rw rw
RM0432 Rev 6
23 22 21 20
rw rw rw rw
7 6 5 4
DTRBS[4:0]
rw rw rw rw
RM0432
19 18 17 16
rw rw rw rw
3 2 1
Res. Res. Res.
rw
0
