The user can enable or disable the above interrupt sources individually by changing the
mask bits or the general interrupt control bit IE in the RNG_CR register. The status of the
individual interrupt sources can be read from the RNG_SR register.
Note: Interrupts are generated only when RNG is enabled.
33.5 RNG processing time
In NIST compliant configuration, the time between two sets of four 32-bit data is either:
•
412 AHB cycles if f
•
256 RNG cycles f
With f
threshold
Note: When CLKDIV is different from zero, f
Table 222. RNG interrupt requests
Interrupt event Event flag
Data ready flag
Seed error flag
Clock error flag
< f
AHB threshold
≥ f
AHB threshold
= 1.6 x f , e.g. 77 MHz if f
AHB
Enable control bit
DRDY IE
SEIS IE
CEIS IE
(conditioning stage is limiting), or
(noise source stage is limiting).
= 48 MHz.
RNG
must take into account the internal divider ratio.
RNG
RM0432 Rev 6
Interrupt clear method
None (automatic)
Write 0 to SEIS or write
CONDRST to 1 then to 0
Write 0 to CEIS
