Octo-SPI interface (OCTOSPI)
19.6.5 OCTOSPI device configuration register 4 (OCTOSPI_DCR4)
Address offset: 0x0014
Reset value: 0x0000 0000
31 30 29 28
rw rw rw rw
15 14 13 12
rw rw rw rw
Bits 31:0 REFRESH[31:0]: Refresh rate
This field enables the refresh rate feature.
The nCS is released every REFRESH+1 clock cycles for writes, and REFRESH+4 clock
cycles for reads.
Note: These two values can be extended with few clock cycles when refresh occurs during a
0: Refresh disabled
others: Maximum communication length is set to REFRESH+1 clock cycles.
19.6.6 OCTOSPI status register (OCTOSPI_SR)
Address offset: 0x0020
Reset value: 0x0000 0000
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
Res. Res.
r
Bits 31:14 Reserved, must be kept at reset value.
Bits 13:8 FLEVEL[5:0]: FIFO level
This field gives the number of valid bytes that are being held in the FIFO. FLEVEL=0 when
the FIFO is empty, and 32 when it is full.
In Automatic-status polling mode, FLEVEL is zero.
Bits 7:6 Reserved, must be kept at reset value.
Bit 5 BUSY: Busy
This bit is set when an operation is ongoing. It is cleared automatically when the operation
with the external device is finished and the FIFO is empty.
Bit 4 TOF: Timeout flag
This bit is set when timeout occurs. It is cleared by writing 1 to CTOF.
