18.7.1 External memory interface signals
Table 88,
Flash memory, SRAM and PSRAM.
Note: The prefix "N" identifies the signals that are active low.
NOR Flash memory, non-multiplexed I/Os
The maximum capacity is 512 Mbits (26 address lines).
Table 87. Programmable NOR/PSRAM access parameters
Function
Duration of the address
setup phase
Duration of the address hold
phase
Duration of the byte lanes
setup phase
Duration of the data setup
phase
Duration of the data hold
phase
Duration of the bus
turnaround phase
Number of AHB clock cycles
(HCLK) to build one memory
clock cycle (CLK)
Number of clock cycles to
issue to the memory before
the first data of the burst
Table 89 and Table 90
Table 88. Non-multiplexed I/O NOR Flash memory
FMC signal name
CLK
A[25:0]
D[15:0]
NE[x]
NOE
NWE
NL(=NADV)
NWAIT
Flexible static memory controller (FSMC)
Access mode
Asynchronous
Asynchronous,
muxed I/Os
Asynchronous
Asynchronous
Asynchronous
Asynchronous and
synchronous read
/ write
Synchronous
Synchronous
list the signals that are typically used to interface with NOR
I/O
O
O
I/O
O
O
O
Latch enable (this signal is called address
O
valid, NADV, by some NOR Flash devices)
I NOR Flash wait input signal to the FMC
