ST STM32L4+ Series Reference Manual page 1014

DSI Host (DSIHOST) applied to STM32L4R9xx and STM32L4S9xx only
30.15.44 DSI Host Interrupt Enable Register 1 (DSI_IER1)
Address offset: 0x00C8
Reset value: 0x0000 0000
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
GPRXE
Res. Res. Res.
IE
rw
Bits 31: 13 Reserved, must be kept at reset value
Bit 12 GPRXEIE: Generic Payload Receive Error Interrupt Enable
Bit 11 GPRDEIE: Generic Payload Read Error Interrupt Enable
Bit 10 GPTXEIE: Generic Payload Transmit Error Interrupt Enable
Bit 9 GPWREIE: Generic Payload Write Error Interrupt Enable
Bit 8 GCWREIE: Generic Command Write Error Interrupt Enable
Bit 7 LPWREIE: LTDC Payload Write Error Interrupt Enable
Bit 6 EOTPEIE: EoTp Error Interrupt Enable
1014/2301
27 26 25
Res. Res. Res.
11 10 9
GPRDE GPTXE GPWRE GCWR
IE IE IE
rw rw rw
This bit enables the interrupt generation on Generic Payload Receive Error.
0: Interrupt on Generic Payload Receive Error disabled.
1: Interrupt on Generic Payload Receive Error enabled.
This bit enables the interrupt generation on Generic Payload Read Error.
0: Interrupt on Generic Payload Read Error disabled.
1: Interrupt on Generic Payload Read Error enabled.
This bit enables the interrupt generation on Generic Payload Transmit Error.
0: Interrupt on Generic Payload Transmit Error disabled.
1: Interrupt on Generic Payload Transmit Error enabled.
This bit enables the interrupt generation on Generic Payload Write Error.
0: Interrupt on Generic Payload Write Error disabled.
1: Interrupt on Generic Payload Write Error enabled.
This bit enables the interrupt generation on Generic Command Write Error.
0: Interrupt on Generic Command Write Error disabled.
1: Interrupt on Generic Command Write Error enabled.
This bit enables the interrupt generation on LTDC Payload Write Error.
0: Interrupt on LTDC Payload Write Error disabled.
1: Interrupt on LTDC Payload Write Error enabled.
This bit enables the interrupt generation on EoTp Error.
0: Interrupt on EoTp Error disabled.
1: Interrupt on EoTp Error enabled.
24 23 22 21
Res. Res. Res. Res.
8 7 6 5
LPWR EOTPE PSE
EIE EIE IE IE
rw rw rw rw
RM0432 Rev 6
20 19 18 17
Res. Res. Res. Res.
4 3 2
CRCE ECCM ECCSE TOLPRX
IE EIE IE IE
rw rw rw rw
RM0432
16
Res.
1 0
TOHSTX
IE
rw
