RM0432
12.6.5
DMAMUX request generator interrupt status register
(DMAMUX_RGSR)
Address offset: 0x140
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 OF[3:0]: Trigger overrun event flag
The flag is set when a new trigger event occurs on DMA request generator channel x, before
the request counter underrun (the internal request counter programmed via the GNBREQ
field of the DMAMUX_RGxCR register).
The flag is cleared by writing 1 to the corresponding COFx bit in the DMAMUX_RGCFR
register.
12.6.6
DMAMUX request generator interrupt clear flag register
(DMAMUX_RGCFR)
Address offset: 0x144
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 COF[3:0]: Clear trigger overrun event flag
Writing 1 in each bit clears the corresponding overrun flag OFx in the DMAMUX_RGSR
register.
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
DMA request multiplexer (DMAMUX)
24
23
22
Res.
Res.
Res.
8
7
6
Res.
Res.
Res.
24
23
22
Res.
Res.
Res.
8
7
6
Res.
Res.
Res.
RM0432 Rev 6
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
Res.
Res.
OF3
OF2
r
r
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
Res.
Res.
COF3
COF2
w
w
17
16
Res.
Res.
1
0
OF1
OF0
r
r
17
16
Res.
Res.
1
0
COF1
COF0
w
w
413/2301
