RM0432
31 30 29
Res. Res. Res.
15 14 13
rw rw rw
Bits 31:17 Reserved, must be kept at reset value.
WRP2 Area A address option bytes
Flash memory address: 0x1FF0 1018
ST production value: 0x0000 00FF
31 30 29
Res. Res. Res.
15 14 13
Res. Res. Res.
Bits 31:24 Reserved, must be kept at reset value.
Bits 23:16 WRP2A_END: WRP first area "A" end offset
WRP Area B address option bytes
Flash memory address: 0x1FF0 1020
ST production value: 0x0000 00FF
28 27 26 25
Res. Res. Res. Res.
12 11 10 9
rw rw rw rw
Bits 16:0 PCROP2_END[16:0]: PCROP area end offset
DBANK=1
PCROP2_END contains the last double-word of the PCROP area for bank2.
DBANK=0
PCROP2_END contains the last 2xdouble-word of the PCROP area for all the
memory.
28 27 26 25
Res. Res. Res. Res.
12 11 10 9
Res. Res. Res. Res.
DBANK=1
WRP2A_END contains the last page of the WRP first area for bank2.
DBANK=0
WRP2A_END contains the last page of the WRP third area for all memory.
Bits 15:8 Reserved, must be kept at reset value.
Bits 7:0 WRP2A_STRT: WRP first area "A" start offset
DBANK=1
WRP2A_STRT contains the first page of the WRP first area for bank2.
DBANK=0
WRP2A_STRT contains the first page of the WRP third area for all memory.
24 23 22
Res. Res. Res.
8 7 6
PCROP2_END[16:0]
rw rw rw
24 23 22
Res.
rw rw
8 7 6
Res.
rw rw
RM0432 Rev 6
Embedded Flash memory (FLASH)
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
rw rw rw rw
21 20 19 18
WRP2A_END[23:16]
rw rw rw rw
5 4 3 2
WRP2A_STRT[7:0]
rw rw rw rw
17 16
PCRO
Res. P2_EN
D[16:0]
rw
1 0
rw rw
17 16
rw rw
1 0
rw rw
