ST STM32L4+ Series Reference Manual page 794

Parallel synchronous slave interface (PSSI) applied to STM32L4P5xx and STM32LQ5xx only
16-bit data
When EDM[1:0] in PSSI_CR are programmed to 11, the interface transfers 16 bits using the
D[15:0] pins. In this case, two PSSI_PDCK cycles are required to transfer a 32-bit word.
The least-significant half word (bits 15:0) correspond to the first half word transferred, and
the most-significant half-word (bits 31:16) corresponds to the second half word transferred.
Table 168
Table 168. Positioning of captured data bytes in 32-bit words (16-bit width)
Byte address
0
4
FIFO data buffer and error conditions
A eight-word FIFO helps improving performance and avoids overruns and underruns.
If the ready signal (PSSI_RDY) is disabled in receive mode, an overrun error is generated
when a clock active edge occurs when the FIFO is full. In this case, the input data is lost.
If the data enable signal (PSSI_DE) is disabled in transmit mode, an underrun error is
generated when a clock active edge occurs when the FIFO is empty. In this case,
unpredictable data are output.
The OVR_RIS status bit indicates that either an overrun or an underrun occurred. An
interrupt can be generated when these events occur.
25.3.5 PSSI optional control signals
Data Enable (PSSI_DE) alternate function input
The data enable signal, PSSI_DE, is an optional signal. It is driven by the data
source/transmitter in order to indicate that the data is valid to be transferred during the
current cycle. When PSSI_DE is inactive, it means that the data will not be or should not be
sampled by the receiver at the next clock edge.
This alternate function signal can be enabled using the DERDYCFG (bits 20:18 of
PSSI_CR) control bits. PSSI_DE polarity is configured through DEPOL control bit (bit 6 of
PSSI_CR). PSSI_DE is active low when DEPOL is cleared to 0, and high when DEPOL is et
to 1.
The direction of the PSSI_DE signal is defined by the OUTEN value. It is the same as the
data direction.
If the PSSI_DE alternate function input is enabled (through DERDYCFG) in receive mode
(OUTEN cleared to 0), the PSSI samples PSSI_DE on the same PSSI_PDCK edge as the
one used for sampling the data (D[15:0]). If PSSI_DE is active, the sampled data is saved in
the FIFO. Otherwise, the sampled data is considered invalid and discarded. The
transmitting device can use PSSI_DE as a data valid signal, driving it inactive when the data
in the current cycle is not valid. This flow control function allows avoiding underrun errors.
794/2301
illustrates the positioning of the data in two 32-bit words.
D
D
31:16
[15:0]
n+1
[15:0]
n+3
RM0432 Rev 6
15:0
D [15:0]
n
D [15:0]
n+2
