STM32F3 Series, STM32F4 Series, STM32L4 Series and
Introduction
This programming manual provides information for application and system-level software
developers. It gives a full description of the STM32 Cortex
model, instruction set and core peripherals.
The STM32F3 Series, STM32F4 Series, STM32L4 Series and STM32L4+ Series
®
Cortex
-M4 processor is a high performance 32-bit processor designed for the
microcontroller market. It offers significant benefits to developers, including:
• Outstanding processing performance combined with fast interrupt handling
• Enhanced system debug with extensive breakpoint and trace capabilities
• Efficient processor core, system and memories
• Ultra-low power consumption with integrated sleep modes
• Platform security

Reference documents

Available from STMicroelectronics web site www.st.com:
•
STM32F3 Series, STM32F4 Series, STM32L4 Series and STM32L4+ Series
datasheets
•
STM32F3 Series, STM32F4 Series, STM32L4 Series and STM32L4+ Series reference
manuals
October 2017
STM32L4+ Series Cortex
DocID022708 Rev 6
Programming manual
®
-M4 programming manual
®
-M4 processor programming
PM0214
1/260
www.st.com
1
