ST STM32L4+ Series Reference Manual page 717

RM0432
31 30 29 28 27
Res. Res. Res. Res. Res.
15 14 13 12 11
Res. Res. Res. Res. Res.
Bits 31:27 Reserved, must be kept at reset value.
Bit 26 JQOVF_SLV: Injected Context Queue Overflow flag of the slave ADC
Bit 25 AWD3_SLV: Analog watchdog 3 flag of the slave ADC
Bit 24 AWD2_SLV: Analog watchdog 2 flag of the slave ADC
Bit 23 AWD1_SLV: Analog watchdog 1 flag of the slave ADC
Bit 22 JEOS_SLV: End of injected sequence flag of the slave ADC
Bit 21 JEOC_SLV: End of injected conversion flag of the slave ADC
Bit 20 OVR_SLV: Overrun flag of the slave ADC
This bit is a copy of the OVR bit in the corresponding ADC_ISR register.
Bit 19 EOS_SLV: End of regular sequence flag of the slave ADC. This bit is a copy of the EOS bit in
the corresponding ADC_ISR register.
Bit 18 EOC_SLV: End of regular conversion of the slave ADC
Bit 17 EOSMP_SLV: End of Sampling phase flag of the slave ADC
Bit 16 ADRDY_SLV: Slave ADC ready
Bits 15:11 Reserved, must be kept at reset value.
Bit 10 JQOVF_MST: Injected Context Queue Overflow flag of the master ADC
Bit 9 AWD3_MST: Analog watchdog 3 flag of the master ADC
Bit 8 AWD2_MST: Analog watchdog 2 flag of the master ADC
Bit 7 AWD1_MST: Analog watchdog 1 flag of the master ADC
Bit 6 JEOS_MST: End of injected sequence flag of the master ADC
26 25 24
JQOVF_ AWD3_ AWD2_
SLV SLV SLV
r r r
10 9 8
JQOVF_ AWD3_ AWD2_
MST MST MST
r r r
This bit is a copy of the JQOVF bit in the corresponding ADC_ISR register.
This bit is a copy of the AWD3 bit in the corresponding ADC_ISR register.
This bit is a copy of the AWD2 bit in the corresponding ADC_ISR register.
This bit is a copy of the AWD1 bit in the corresponding ADC_ISR register.
This bit is a copy of the JEOS bit in the corresponding ADC_ISR register.
This bit is a copy of the JEOC bit in the corresponding ADC_ISR register.
This bit is a copy of the EOC bit in the corresponding ADC_ISR register.
This bit is a copy of the EOSMP2 bit in the corresponding ADC_ISR register.
This bit is a copy of the ADRDY bit in the corresponding ADC_ISR register.
This bit is a copy of the JQOVF bit in the corresponding ADC_ISR register.
This bit is a copy of the AWD3 bit in the corresponding ADC_ISR register.
This bit is a copy of the AWD2 bit in the corresponding ADC_ISR register.
This bit is a copy of the AWD1 bit in the corresponding ADC_ISR register.
This bit is a copy of the JEOS bit in the corresponding ADC_ISR register.
23 22 21
AWD1_ JEOS_ JEOC_
SLV SLV SLV
r r r
7 6 5
AWD1_ JEOS_ JEOC_
MST MST MST
r r r
RM0432 Rev 6
Analog-to-digital converters (ADC)
20 19 18
OVR_ EOS_ EOC_
SLV SLV SLV
r r r
4 3 2
OVR_ EOS_ EOC_
MST MST MST
r r r
17 16
EOSMP_ ADRDY_
SLV SLV
r r
1 0
EOSMP_ ADRDY_
MST MST
r r
