Digital camera interface (DCMI)
24.5.8
DCMI embedded synchronization unmask register (DCMI_ESUR)
Address offset: 0x1C
Reset value: 0x0000 0000
31
30
29
rw
rw
rw
15
14
13
rw
rw
rw
Bits 31:24 FEU[7:0]: Frame end delimiter unmask
Bits 23:16 LEU[7:0]: Line end delimiter unmask
Bits 15:8 LSU[7:0]: Line start delimiter unmask
Bits 7:0 FSU[7:0]: Frame start delimiter unmask
24.5.9
DCMI crop window start (DCMI_CWSTRT)
Address offset: 0x20
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
15
14
13
Res.
Res.
rw
786/2301
28
27
26
25
FEU[7:0]
rw
rw
rw
rw
12
11
10
9
LSU[7:0]
rw
rw
rw
rw
This byte specifies the mask to be applied to the code of the frame end delimiter.
0: The corresponding bit in the FEC byte in DCMI_ESCR is masked while comparing the
frame end delimiter with the received data.
1: The corresponding bit in the FEC byte in DCMI_ESCR is compared while comparing the
frame end delimiter with the received data.
This byte specifies the mask to be applied to the code of the line end delimiter.
0: The corresponding bit in the LEC byte in DCMI_ESCR is masked while comparing the line
end delimiter with the received data.
1: The corresponding bit in the LEC byte in DCMI_ESCR is compared while comparing the
line end delimiter with the received data.
This byte specifies the mask to be applied to the code of the line start delimiter.
0: The corresponding bit in the LSC byte in DCMI_ESCR is masked while comparing the line
start delimiter with the received data.
1: The corresponding bit in the LSC byte in DCMI_ESCR is compared while comparing the
line start delimiter with the received data.
This byte specifies the mask to be applied to the code of the frame start delimiter.
0: The corresponding bit in the FSC byte in DCMI_ESCR is masked while comparing the
frame start delimiter with the received data.
1: The corresponding bit in the FSC byte in DCMI_ESCR is compared while comparing the
frame start delimiter with the received data.
28
27
26
25
rw
rw
rw
rw
12
11
10
9
rw
rw
rw
rw
24
23
22
rw
rw
rw
8
7
6
rw
rw
rw
24
23
22
VST[12:0]
rw
rw
rw
8
7
6
HOFFCNT[13:0]
rw
rw
rw
RM0432 Rev 6
21
20
19
18
LEU[7:0]
rw
rw
rw
rw
5
4
3
2
FSU[7:0]
rw
rw
rw
rw
21
20
19
18
rw
rw
rw
rw
5
4
3
2
rw
rw
rw
rw
RM0432
17
16
rw
rw
1
0
rw
rw
17
16
rw
rw
1
0
rw
rw
