DCMI masked interrupt status register (DCMI_MIS)

This DCMI_MIS register is a read-only register. When read, it returns the current masked

status value (depending on the value in DCMI_IER) of the corresponding interrupt. A bit in

this register is set if the corresponding enable bit in DCMI_IER is set and the corresponding

bit in DCMI_RIS is set.

Address offset: 0x10

Reset value: 0x0000 0000

Bits 31:5 Reserved, must be kept at reset value.

Bit 4 LINE_MIS: Line masked interrupt status

Bit 3 VSYNC_MIS: VSYNC masked interrupt status

Bit 2 ERR_MIS: Synchronization error masked interrupt status

Note: This bit is available only in embedded synchronization mode.

Bit 1 OVR_MIS: Overrun masked interrupt status

Bit 0 FRAME_MIS: Capture complete masked interrupt status

This bit gives the status of the masked line interrupt.

0: No interrupt generation when the line is received

1: An Interrupt is generated when a line has been completely received and the LINE_IE bit

is set in DCMI_IER.

This bit gives the status of the masked VSYNC interrupt.

0: No interrupt is generated on DCMI_VSYNC transitions.

1: An interrupt is generated on each DCMI_VSYNC transition from the inactive to the active

state and the VSYNC_IE bit is set in DCMI_IER.

The active state of the DCMI_VSYNC signal is defined by the VSPOL bit.

This bit gives the status of the masked synchronization error interrupt.

0: No interrupt is generated on a synchronization error.

1: An interrupt is generated if the embedded synchronization codes are not received in the

correct order and the ERR_IE bit in DCMI_IER is set.

This bit gives the status of the masked overflow interrupt.

0: No interrupt is generated on overrun.

1: An interrupt is generated if the DMA was not able to transfer the last data before new

data (32-bit) are received and the OVR_IE bit is set in DCMI_IER.

This bit gives the status of the masked capture complete interrupt

0: No interrupt is generated after a complete capture.

1: An interrupt is generated at the end of each received frame/crop window (in crop mode)

and the FRAME_IE bit is set in DCMI_IER.
