show lldp port local-info
Parameters
port-string
Defaults
If port‐string is not specified, local system information will be displayed for all ports.
Mode
Switch command, Read‐Only.
Usage
You can use this information to detect misconfigurations or incompatibilities between the local
port and the attached endpoint device (remote port).
Example
This example shows how to display the local system information stored for port fe.4.1. Table
describes the output fields of this command.
Matrix(rw)->show lldp port local-info fe.4.1
Local Port
--------------------
Port Desc
Mgmt Addr
Chassis ID
Sys Name
Sys Desc
Sys Cap Supported/Enabled
Auto-Neg Supported/Enabled
Auto-Neg Advertised
Table 3‐4 describes the information displayed by the show lldp port local‐info command.
Table 3-4 show lldp port local-info Output Details
Output...
Local Port
Local Port Id
Port Desc
Mgmt Addr
Chassis ID
(Optional) Displays local system information for one or a range of
ports.
: fe.4.1 Local Port Id: fe.4.1
: ... 100BASE-TX RJ21 Fast Ethernet Frontpanel Port
: 10.21.64.100
: 00-E0-63-93-74-A5
: LLDP PoE test Chassis
: Enterasys Networks, Inc. Matrix E7 Gold Rev 05.41
: bridge,router/bridge
: yes/yes
: 10BASE-T, 10BASE-TFD,
What it displays...
Identifies the port for which local system information is displayed.
Mandatory basic LLDP TLV that identifies the port transmitting the
LLDPDU. Value is ifName object defined in RFC 2863.
Optional basic LLDP TLV. Value is ifDescr object defined in RFC 2863.
Optional basic LLDP TLV. IPv4 address of host interface.
Mandatory basic LLDP TLV that identifies the chassis transmitting the
LLDPDU. Value is MAC address of chassis.
Link Layer Discovery Protocol and LLDP-MED
100BASE-TX, 100BASE-TXFD,
1000BASE-TFD,
Bpause
Enterasys Matrix DFE-Gold Series Configuration Guide 3-21
