Enterasys Matrix DFE-Gold Series Configuration Manual page 253

set port lacp
aadminstate
lacpactive |
lacptimeout | lacpagg
| lacpsync |
lacpcollect | lacpdist
| lacpdef | lacpexpire
padminsyspri
padminsyspri
padminsysid
padminsysid
padminkey padminkey Sets a default value to use as the port's partner admin key. Only ports
padminportpri
padminportpri
padminport
padminport
padminstate
lacpactive |
lacptimeout | lacpagg
| lacpsync |
lacpcollect | lacpdist
| lacpdef | lacpexpire
enable
disable
Defaults
• At least one parameter must be entered per port‐string.
• If enable or disable are not specified, port(s) will be enabled with the LACP parameters
entered.
Mode
Switch command, Read‐Write.
Usage
These settings will determine the specified underlying physical ports' ability to join a LAG, and
their administrative state once aggregated.
LACP commands and parameters beginning with an "a" (such as aadminkey) set actor values.
Corresponding commands and parameters beginning with a "p" (such as padminkey) set
corresponding partner values. Actor refers to the local device participating in LACP negotiation,
while partner refers to its remote device partner at the other end of the negotiation. Actors and
Sets the port's actor LACP administrative state to allow for:
• lacpactive ‐ Transmitting LACP PDUs.
• lacptimeout ‐ Transmitting LACP PDUs every 1 sec. vs 30 sec.
(default).
• lacpagg ‐ Aggregation on this port.
• lacpsync ‐ Transition to synchronization state.
• lacpcollect ‐ Transition to collection state.
• lacpdist ‐ Transition to distribution state.
• lacpdef ‐ Transition to defaulted state.
• lacpexpire ‐ Transition to expired state.
Sets a default value to use as the port's partner priority. Valid values are
0 ‐ 65535, with lower values given higher priority.
Sets a default value to use as the port's partner system ID. This is a
MAC address.
with matching admin keys are allowed to aggregate. Valid values are 1 ‐
65535.
Sets a default value to use as the port's partner port priority. Valid
values are 0 ‐ 65535, with lower values given higher priority.
Sets a default value to use as the port's partner admin value. Valid
values are 1 ‐ 65535.
Sets a port's partner LACP administrative state. See aadminstate for
valid options.
(Optional) Enables LACPDU processing on this port.
(Optional) Disables LACPDU processing on this port.
Enterasys Matrix DFE-Gold Series Configuration Guide 4-67
Configuring LACP
