Enterasys Matrix DFE-Gold Series Configuration Manual page 760

Configuring VRRP
Usage
You must execute the router vrrp command to enable the protocol before completing other VRRP‐
specific configuration tasks. For details on enabling configuration modes, refer to Table
"Enabling Router Configuration Modes" on page 2‐103.
The "no" form of this command removes all VRRP configurations from the running configuration.
Example
This example shows how enable VRRP configuration mode:
Matrix>Router#configure terminal
Matrix>Router(config)#router vrrp
Matrix>Router(config-router)#
create
Use this command to create a VRRP session.
Syntax
create vlan vlan-id vrid
no create vlan vlan-id vrid
Parameters
vlan vlan‐id
vrid
Defaults
None.
Mode
Router command, Router configuration: Matrix>Router(config‐router)#
Usage
This command must be executed to create an instance of VRRP on a routing interface (VLAN)
before any other VRRP settings can be configured.
Each Enterasys Matrix Series Gold routing module supports up to 128 VRRP sessions. Up to four
VRIDs can be associated with an individual routing interface.
The "no" form of this command disables the VRRP session.
Example
This example shows how to create a VRRP session on VLAN 1 with a VRID of 1:
Matrix>Router(config)#router vrrp
Matrix>Router(config-router)#create vlan 1 1
21-62 Routing Protocol Configuration
Specifies the number of the VLAN on which to create a VRRP session.
This VLAN must be configured for IP routing as described in "Pre‐
Routing Configuration Tasks" on page 2‐100.
Specifies a unique Virtual Router ID (VRID) to associate with the
routing interface. The value of vrid can range from 1 to 255.
create
