Purpose
To review and configure Load Sharing Network Address Translation (LSNAT).

LSNAT Configuration Task List and Commands

Table 19‐1 lists the mandatory and optional tasks and commands for configuring LSNAT on the
Enterasys Matrix Series device. Commands are described in the associated sections as shown.
Table 19-1 LSNAT Configuration Task List and Commands
Task
Configure a server farm:
(Optional) Display the server farm configuration.
(Optional) Define an FTP control port.
Specify a server farm name.
Specify a real server as a member of the server farm.
(Optional) Specify a load balancing algorithm.
(Optional) Configure this server farm to use sticky session
persistence. (See "Sticky Persistence Configuration
Considerations" on page 19-2 for more information.)
Configure a real server:
(Optional) Display the real server configuration.
Enable a real server for service.
(Optional) Configure real server error handling.
(Optional) Set the ACV command string to send to the
server application port.
(Optional) Set the expected validation ACV reply string
from the server application port.
(Optional) Issue a command to close the session.
(Optional) Set an exact acv-reply string index when the
file is not known to the user.
(Optional) Limit active connections to the real server.
(Optional) Specify a weight load number for the real
server.
Configure a virtual server:
(Optional) Display the virtual server configuration.
Specify a virtual server name.
Configuring Load Sharing Network Address Translation (LSNAT)
Use these commands...
show ip slb serverfarms
serverfarms" on page 19-6)
ip slb ftpctrlport ("ip slb
page 19-7)
ip slb serverfarm
page 19-8)
real ("real" on page 19-8)
predictor ("predictor" on page 19-9)
sticky ("sticky" on page 19-10)
show ip slb reals
page 19-10)
inservice ("inservice (real
page 19-13)
faildetect ("faildetect (real
page 19-13)
faildetect acv-command
command" on page 19-15)
faildetect acv-reply
page 19-16)
faildetect acv-quit
page 19-16)
faildetect read-till-index
index" on page 19-17)
maxconns ("maxconns" on page 19-18)
weight ("weight" on page 19-18)
show ip slb vservers
page 19-19)
ip slb vserver ("ip slb
Enterasys Matrix DFE-Gold Series Configuration Guide 19-5
("show ip slb
ftpctrlport" on
("ip slb serverfarm" on
("show ip slb reals" on
server)" on
server)" on
("faildetect acv-
("faildetect acv-reply" on
("faildetect acv-quit" on
("faildetect read-till-
("show ip slb vservers" on
vserver" on page 19-21)
