set cep detection-id porthigh | portlow

Parameters
id
tcp | udp | both |
none
Defaults
None.
Mode
Switch command, Read‐Write.
Usage
This command applies only to Siemens, H.323, and SIP phone detection. Cisco detection uses
CiscoDP as its discovery method.
If an IP address is not set for a phone detection group as described in "set cep detection‐id
address" on page 25‐46, this will configure detection on UDP and/or TCP ports using a port range
defined with the set cep detection‐id porthigh | portlow command as described in "set cep
detection‐id porthigh | portlow" on page 25‐47.
Example
This example shows how to enable both TCP and UDP convergence end points detection for CEP
detection group 1:
Matrix>set cep detection-id 1 protocol both
set cep detection-id porthigh | portlow
Use this command to set the maximum and minimum ports used for TCP or UDP convergence
end points detection.
Syntax
set cep detection-id id { porthigh | portlow } port
Parameters
id
porthigh | portlow
port
Defaults
None.
Configuring Convergence End Points (CEP) Phone Detection
Specifies a CEP configuration group ID. This group must be created
and enabled using the set cep detection‐id command as described in
"set cep detection‐id" on page 25‐44. Valid values are 1 ‐ 2147483647.
Sets the CEP IP protocol type to be used for detection as:
• TCP
• UDP
• Both UDP and TCP
• None
Specifies a CEP configuration group ID. This group must be created
and enabled using the set cep detection‐id command as described in
"set cep detection‐id" on page 25‐44. Valid values are 1 ‐ 2147483647.
Specifies a maximum or minimum UDP or TCP port for CEP
detection.Valid values are 1 ‐ 65535.
