Configuring OSPF
Parameters
vlan vlan‐id
Defaults
If vlan‐id is not specified, OSPF statistics will be displayed for all VLANs.
Mode
Router command, Any router mode.
Example
This example shows how to display all OSPF related information for VLAN 1:
Matrix>Router#show ip ospf interface vlan 1
Vlan
Internet Address
Router ID 182.127.64.1,Network Type BROADCAST,Cost: 10
Transmit Delay is 1 sec,State BACKUPDR,Priority 1
Designated Router id 182.127.62.1, Interface addr 182.127.63.1
Backup Designated Router id 182.127.63.2,
Timer intervals configured, Hello 10,Dead 40,Wait 40,Retransmit 5
Neighbor Count is 1, Adjacent neighbor count is 1
Adjacent with neighbor 182.127.63.1 (Designated Router)
Table 21‐4 provides an explanation of the command output.
Table 21-4 show ip ospf interface Output Details
Output...
Vlan
Internet Address
Router ID
Network Type
Cost
Transmit Delay
State
Priority
Designated Router id
Interface addr
Backup Designated
Router id
21-46 Routing Protocol Configuration
(Optional) Displays OSPF information for a specific VLAN. This VLAN
must be configured for IP routing as described in "Pre‐Routing
Configuration Tasks" on page 2‐100.
1 is UP
182.127.63.2
What it displays...
Interface (VLAN) administrative status as up or down.
IP address and mask assigned to this interface.
Router ID, which OSPF selects from IP addresses configured on this router.
OSPF network type, for instance, broadcast.
OSPF interface cost, which is either default, or assigned with the ip ospf cost
command. For details, refer to
The number (in seconds) added to the LSA (Link State Advertisement) age field.
The interface state (versus the state between neighbors). Valid values include
BACKUPDR (Backup Designated Router), and DR (Designated Router).
The interface priority value, which is either default, or assigned with the ip ospf
priority command. For details, refer to
The router ID of the designated router on this subnet, if one exists.
IP address of the designated router on this interface.
IP address of the backup designated router on this interface, if one exists.
Mask 255.255.255.0,Area 0.0.0.0
"ip ospf cost" on page 21-24.
"ip ospf
show ip ospf interface
priority" on page 21-25.
