Mgmt Addr : 10.21.64.100
Chassis ID : 00-E0-63-93-74-A5
Sys Name : LLDP PoE test Chassis
Sys Desc : Enterasys Networks, Inc.
Sys Cap Supported/Enabled
Auto-Neg Supported/Enabled
Auto-Neg Advertised
Operational Speed/Duplex/Type : 100 full tx
Max Frame Size (bytes)
Vlan Id
LAG Supported/Enabled/Id
Protocol Id : Spanning Tree v-3 (IEEE802.1s)
LACP v-1
GVRP
Network Policy
(app/tag/vlanId/cos/dscp)
ECS ELIN : 1234567890123456789012345
PoE Device
PoE Power Source
PoE MDI Supported/Enabled
PoE Pair Controllable/Used
PoE Power Class
PoE Power Limit (mW)
PoE Power Priority
Table 6‐4 describes the information displayed by the show lldp port local‐info command.
Table 6-4 show lldp port local-info Output Details
Output Field
Local Port
Local Port Id
Port Desc
Mgmt Addr
Chassis ID
Sys Name
Sys Desc
Sys Cap Supported/Enabled
: bridge,router/bridge
: yes/yes
: 10BASE-T, 10BASE-TFD,
100BASE-TX, 100BASE-TXFD,
1000BASE-TFD,
Bpause
: 1522
: 1
: no/no/0
: voice/tagged/10/3/5
voice signaling/tagged/10/3/5
guest voice/tagged/10/3/5
guest voice signaling/tagged/10/3/5
softphone voice/tagged/10/3/5
video conferencing/tagged/10/3/5
streaming video/tagged/10/3/5
video signaling/tagged/10/3/5
: PSE device
: primary
: yes/yes
: false/spare
: 2
: 15400
: high
What it Displays...
Identifies the port for which local system information is displayed.
Mandatory basic LLDP TLV that identifies the port transmitting the
LLDPDU. Value is ifName object defined in RFC 2863.
Optional basic LLDP TLV. Value is ifDescr object defined in RFC 2863.
Optional basic LLDP TLV. IPv4 address of host interface.
Mandatory basic LLDP TLV that identifies the chassis transmitting the
LLDPDU. Value is MAC address of chassis.
Optional basic LLDP TLV. Value is the administratively assigned name for
the system.
Optional basic LLDP TLV. Value is sysDescr object defined in RFC 3418.
Optional basic LLDP TLV. System capabilities, value can be bridge and/or
router.
show lldp port local-info
