show port egress

Configuring the VLAN Egress List

Purpose

To assign or remove ports on the egress list of a particular VLAN. This determines which ports
will be eligible to transmit frames for a particular VLAN. For example, ports 1, 5, 9, 8 could be
assigned to transmit frames belonging to VLAN 5 (VLAN ID=5).
The port egress type for all ports defaults to tagging transmitted frames, but can be changed to
forbidden or untagged. In general, VLANs have no egress (except for VLAN 1) until they are
configured by static administration, or through dynamic mechanisms (i.e., GVRP, policy
classification or Enterasys dynamic egress).
Setting a port to forbidden prevents it from participating in the specified VLAN and ensures that
any dynamic requests (either through GVRP or dynamic egress) for the port to join the VLAN will
be ignored. Setting a port to untagged allows it to transmit frames without a tag header. This
setting is usually used to configure a port connected to an end user device.
The default VLAN defaults its egress to untagged for all ports.

Commands

For information about...
show port egress
set vlan egress
clear vlan egress
show vlan dynamic egress
set vlan dynamicegress
show port egress
Use this command to display the VLAN membership for one or more ports.
Syntax
show port egress [port-string]
Parameters
port‐string
Defaults
If port‐string is not specified, VLAN membership will be displayed for all ports.
Mode
Switch command, Read‐Write.
(Optional) Displays VLAN membership for specific port(s). For a
detailed description of possible port‐string values, refer to "Port String
Syntax Used in the CLI" on page 4‐2.
Enterasys Matrix DFE-Gold Series Configuration Guide 7-17
Configuring the VLAN Egress List
Refer to page...
7-17
7-18
7-19
7-20
7-20
